Product Summary

The AQV210EH is a photoMOS relay.

Parametrics

AQV210EH absolute maximum ratings: (1)Mounting Type: Through Hole; (2)Termination Style: PC Pin; (3)Package / Case: 6-DIP (0.300", 7.62mm); (4)Circuit: SPST-NO (1 Form A); (5)Load Current: 130mA; (6)Voltage Input: 1.14VDC; (7)Voltage Load: 0 to 350V; (8)Output Type: AC, DC; (9)On-State Resistance: 35 Ohm; (10)Lead Free Status: Lead Free.

Features

AQV210EH features: (1)PhotoMOS relay; (2)PhotoMOS Schematic & Wiring Diagrams; (3)Product Training Modules PhotoMOS Solid State Relays.

Diagrams

AQV210EH PhotoMOS Relay Dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AQV210EH
AQV210EH
Panasonic Electric Works
Solid State Relays 130MA 350V 6PIN SPST
Data Sheet
0-1: $1.79
1-25: $1.64
25-50: $1.46
50-100: $1.40
AQV210EHA
AQV210EHA
Panasonic Electric Works
Solid State Relays 130MA 350V 6PIN SPST
Data Sheet
0-1: $1.84
1-25: $1.69
25-50: $1.50
50-100: $1.44
AQV210EHAX
AQV210EHAX
Panasonic Electric Works
Solid State Relays 350v 130mA DIP Form A Norm-Open
Data Sheet
0-1000: $1.42
1000-3000: $1.37
3000-5000: $1.29
AQV210EHAZ
AQV210EHAZ
Panasonic Electric Works
Solid State Relays 350v 130mA DIP Form A Norm-Open
Data Sheet
0-1000: $1.42
1000-3000: $1.37
3000-5000: $1.29
